Pneumatic Scotch Yoke Actuator
Powerful and efficient quarter-turn control with compact design. Available in double-acting or spring-return configurations for fail-safe operation.
Key Features
Built with corrosion-resistant materials and long-life seals for demanding field use.
Quarter-turn Rotary Motion
Precise 90-degree rotation for optimal valve control and positioning.
Double-acting or Spring-return
Flexible configuration options for different operational requirements.
Compact Design
Space-efficient design without compromising on performance or reliability.
Corrosion-resistant Materials
Built to withstand harsh environmental conditions and corrosive media.
Optional Features
Feedback, solenoid, or manual override options available for enhanced functionality.
Efficient Operation
Optimized design for maximum efficiency and minimal energy consumption.
Applications
Our pneumatic scotch yoke actuators are designed for demanding applications across various industries.
Oil & Gas
Reliable operation in upstream, midstream, and downstream applications with fail-safe capabilities.
Petrochemical
Corrosion-resistant design for handling aggressive chemicals and high-temperature processes.
Automation Systems
Precise control for automated manufacturing and processing systems.
Specifications
Technical specifications for our pneumatic scotch yoke actuators.
| Parameter | Specification |
|---|---|
| Operating Pressure | 2-10 bar (29-145 psi) |
| Temperature Range | -20°C to +80°C (-4°F to +176°F) |
| Rotation Angle | 90° ± 2° |
| Torque Range | 10-10000 Nm (7-7376 lb-ft) |
| Body Material | Aluminum, Cast Iron, Stainless Steel |
| Piston Material | Aluminum, Steel, Stainless Steel |
| Seal Material | NBR, Viton, EPDM, PTFE |
| Mounting | Direct Mount, ISO 5211 |
